Hardware Specification
CPU
Intel G540 2.5Ghz/2M cacheIntel Core i3-2120 3.3Ghz/3M cacheIntel Core i3-3220 3.3Ghz/3M cacheIntel Core i5-3550s 3.7Ghz/6M cache
Chipset
Intel® H61 Chipset
System Memory
2GB Standard, Maximum 16G (240-pin DDR3 x 2)
Audio
Realtek ALC887 HD Audio
Display
17” /19” TFT-LCD /1280 X 1024
Touch Screen: 5-wired resistive
Storage
2.5” SATA HDD/SSD
Color
Black / White
Power supply
250W PSU
External I/O Ports
USB 2.0
4, optional 1 x front + 2 x rear
COM port
1 x DB-9(no power), optional 4 x DB-9 with RI/5V/12V selectable
PS2
1 x keyboard , 1 x mouse
Parallel
1
LAN
1 x RJ45 10/100/1000Mbps
Audio I/O
3 ; MIC and Line-in/out
Expansion Slot
PCIe x 16
PCIe x 1
2
Optional Peripherals
Multi-card Reader
5 in 1 multi card reader (USB)
DVD ROM
DVD-RW
MSR
3 Tracks , JIS-I or II
2-in-1 Reader
MSR+i-Button
Customer Display
2 x 20 VFD/ 4 line 7” colourful VFD (USB), VESA mount
OS Support
Windows
POSReady 2009,win XP,POSReady 7,Win 7
Environment
Green Product
RoHs,REACH
EMI/Safety
CE CLASS A,FCC Part 15 Subpart B,CLASS A
Operating Temperature
0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature
-10°C ~ 55°C (14°F ~131°F)
Relative Humidity
10% ~ 90% (Non-Condensing)
Dimension
Dimension 17”/19”
426(W) x 219(D) x 405(H) mm
Weight 17”/19”
12KGS/12.6KGS
Product specifications are subject to change without prior notice.
