| Dimensions |
85mm(L) X 72mm(W) X 17mm(H) |
| Weight |
EZ100PR: approx. 145g
EZ100PU: approx. 120g |
|
Power Consumption
Power Voltage(v) |
EZ100PR/NR:
Powered by keyboard interface,5V±5%,
100mA Max. including card power
EZ100PU:
Powered by USB hub,5V±5%,60mA |
| Card Acceptor / Durability |
Friction type with over 200,000 insertion cycles |
| Connecting Interface |
EZ100PR:
Y-type cable with female D-SUB 9 pin connector and combined with a Y-type Mini-DIN6 cable for power
EZ100PU:
A type USB male 4 pin connector, compliant to USB2.0 (full speed) |
| Compliant IC Card Standard |
CPU card:
Comply with ISO7816-1,2,3 T=1 and T=0 protocol
Memory card:
Synchronous 2-line, 3-line and I2C Interface |
| Driver Support |
EZ100PR/NR-
Win 95/98/ME/2000/NT4.0/XP/CE3.0, Linux; DOS (for NR only)
EZ100PU-
Windows Vista 32 & Vista 64 /Win 98/ME/2000/XP/CE3.0; Linux, MAC OS |
| SDK(Software Library) |
PC/SC compliant, Proprietary API, CT-API |
| Environmental |
Operating Temperature: 0 ~ 50°C
Storage Temperature: -35 ~ 70°C
Operating Humidity: 20% ~ 90% (Not in catalog) |
