 Current Location:Home - Products - AIO POS Terminal

AIO POS Terminal
Product Name:AIO POS Terminal

Product No:115145-870
Model:ECRPOS080
Was Price:0Dollar/Carton Now Price:0Dollar/Carton
Last update:2015.04.27
Manufacturer:UTG Taiwan Global Website
Clicks:
   产品详细介绍
Model Name
EP-6202
System
CPU
Intel Atom Dual core Processor D525 1.8 GHz
Memory
1G DDRIII RAM, up to 4GB
Network
10/100Mbps onboard Ethernet Controller
Storage Device
2.5" 160G HDD
OS Compatibility
Windows XP/XPE, POS Ready, Linux
LCD Display
8" LCD / 800x600
I/O Connectivity
Serial Port
3 x External COM Ports with 5V/12V selectable
USB Port
4 x External USB 2.0 Type A
LAN Port
1 x RJ45 10/100M Base-T
Parallel Port
1 x Bi-directional Parallel
Cash Drawer Port
1 x RJ11 DC 24V
Keyboard Port
1 x PS/2 (Keyboard & Mouse)
VGA Port
1 x VGA (DB15)
Audio Port
1 x Line-out
Printer Paper width
57±0.5 mm, 79±0.5 mm
Printer Printing speed
150 mm/s
Printer Cutter
Tear Bar
Customer Display
LCD 20 chars x 2 Lines
Keyboard
Up to 70 Key programmable
Power Supply
AC 100~240V / 90W power adapter
Mechanical
Housing Color
Black
Dimension(W x D x H)
365 x 390 x 170 mm
Weight
N.W. 5.8 kgs
Display Tilt Angle
10~90 degree
EMI/Safety
CE, FCC Class A
Environment
Operating Temperature
5°C ~ 40°C
Storage Temperature
-20°C ~ 60°C
Relative Humidity
15% ~ 90% RH
Peripherals
Option
MSR / SCR / i-button /Touch Panel / Auto Cutter
