Display |
TFT LCD |
MIPI, LED Backlight 400 cd/m2 |
|
Number of Pixel |
800 RGB (H) x 1280 (V) |
|
Back-light |
LED Side-light type |
|
Touch |
I2C Touch Panel |
10.1” Touch |
|
System |
CPU |
Rockchip RK3399 |
|
Emmc Flash |
16GB |
|
DDR3 DRAM |
2GB |
|
Media format |
Video |
MKV, TS, FLV, AVI, VOB, MPG, DAT, ASF, RM, MOV, 3GP, MP4, WMV |
|
Audio |
MP2, WMA, WAV, AAC, OGG, ASF |
|
Picture |
JPG, BMP, GIF |
|
I/O |
Micro USB |
*1 |
|
Wi-Fi 802.11 b/g/n/ac |
*1 |
|
BT4.2 |
*1 |
|
USB Camera 5M |
*1 [Option] |
|
RGB LED Bar |
*1 |
|
4G LTE |
*1 [Option] |
|
NFC PN553 |
*1 [Option] |
|
Light Sensor |
*1 [Option] |
|
Card Slot |
TF Card Slot |
*1 |
|
Nano Sim Slot Push |
*1 |
|
Antenna |
4G Dongle Internal |
*1 |
|
Wi-Fi Internal |
*1 |
|
NFC Internal |
*1 |
|
Speaker |
2W/8 OHM |
*2 |
|
Power |
Li Polymer Battery 5000mAH |
*1 |
|
Wireless Charge 15W |
*1 note1 |
|
Wire Charge |
*1 note1 |
|
DC IN 12V/2A |
*1 |
|
Key |
Power [with Reset] |
*1 |
|
LED Indicator |
Green |
*1 |
|
Reliability |
Certification |
CE/FCC Class A |
|
IEC 60529 |
IP53/IP54,跌落測?30cm |
|
Environment |
Temperature |
Operation: 0℃ ~ 40℃ ( 32F ~104F)
Storage: -10°C ~ 55°C (14°F ~ 131°F) |
|
|
Humidity |
Operation: 10%-85%
Storage:10% ~ 90% (Non-Condensing) |
Hardware
CPU
- Dual-Core Cortex-A72, up to 1.8GHz. Quad Core Cortex-A53, up to 1.4 GHz
GCPU
-Mali-T860MP4 GPU, support OpenGL ES1.1/2.0/3.0/3.1/3.2, OpenCL1.2, DirectX11.1
System Memory
- 2GB/4GB DDR3 SDRAM
Internal Storage Memory
- 16GB/32GB(option) eMMC
External Storage Memory
- TF Card (SDHC Class10 compatible)
LCD
- 10.1” 800X1280 MIPI digital TFT LCD
Touch Panel Type
-10 point capacitive multi-touch type
Amplifier, Speaker
- Speaker unit: 2W+2W, 8 OHM
- Amplifier 1.25+1.25W
- Save the set-up volume and keep the value at the time of power off and on.
Device Battery
- Li Polymer Battery, 5000mAH
Clock Battery (for RTC)
- Lithium-ion non-rechargeable coin battery
LED
- Power supply ON: Green Light Off.
- Power supply OFF: Green Light off
Wireless Communication Specification
- Wi-Fi：IEEE 802.11a/b/g/n/ac
- Bluetooth 4.2
Ethernet Communication Specification
- 10/100Mbps LAN RJ45 built-in [With Docking]
- POE (optional, With Docking)
External Interface
- TF card slot
- Key Button(Power with Reset)
- Micro USB [Slave]
- Ethernet RJ45 10/100 Mbps connector with docking [option]
- DC adapter port |
