Basic Specification
|
Display |
TFT LCD |
13.3" EDP LCD Panel |
|
Number of Pixel |
1920 RGB (H) x 1080(V) |
|
Back-light |
LED Side-light type |
|
Media format |
Video |
MKV, TS, FLV, AVI, VOB, MPG, DAT, ASF, RM, MOV, 3GP, MP4, WMV |
|
Audio |
MP2, WMA, WAV, AAC, OGG, ASF |
|
Picture |
JPG, BMP, GIF |
|
I/O |
SD card slot |
SD card (SDHC Class10 compatible) |
|
USB |
USB 3.0 host type A×1 |
|
Type C |
USB Type C × 1 (OTG) |
|
Mini-HDMI |
HDMI 1.4 and 2.0 |
|
Add-on Module Slot |
USB 2.0 x 3 |
|
Speaker |
High quality speaker |
2W×2,Ampilifer:1.25Wx2 |
|
Power |
DC adapter |
12V/2A DC adapter |
|
Wireless Communication |
Wi-Fi |
802.11 a/b/g/n/ac |
|
|
Bluetooth |
BT4.2 |
|
Ethernet |
RJ45 |
10/100/1000 Mbps LAN |
|
|
POE |
Power Over Ethernet (optional) |
|
Camera |
Front |
Front: 2M/5M pixels |
|
Function keys |
Key button |
+、-、Up、Down、Exit |
Detail Specification
Hardware
CPU
- Dual-Core Cortex-A72, up to 1.8GHz. Quad Core Cortex-A53, up to 1.4 GHz
GCPU
-Mali-T860MP4 GPU, support OpenGL ES1.1/2.0/3.0/3.1/3.2, OpenCL1.2, DirectX11.1
System Memory
- 2GB/4GB DDR3 SDRAM
Internal Storage Memory
- 16GB/32GB(option) eMMC
External Storage Memory
- SD Card (SDHC Class10 compatible)
LCD
- 11.6” 1920X1080 digital TFT LCD
Touch Panel Type
-10 point capacitive multi-touch type
Amplifier, Speaker
- Speaker unit: 2W+2W
- Amplifier 1.25+1.25W
- Save the set-up volume and keep the value at the time of power off and on.
Clock Battery (for RTC)
- Lithium-ion non-rechargeable coin battery
LED
- Power supply ON: Red then turn Green after kernel boot up.
- Power supply OFF: LED light off
Wireless Communication Specification
- Wi-Fi：IEEE 802.11a/b/g/n/ac
- Bluetooth 4.2
Ethernet Communication Specification
- 10/100/1000Mbps LAN RJ45 built-in
- POE (optional)
External Interface
- SD card slot
- Key button (+、-、Up、Down、Exit)
- USB interface:
USB host type A port （USB 3.0 high speed 5G bps）x 1
USB Type C port （USB 3.0 high speed 5G bps）x 1
Add-on Module slot （USB 2.0 interface high speed 480Mbps）x 3
- Ethernet RJ45 10/100/1000 Mbps connector
- Power switch
- DC adapter port
- Metal-fittings mounting screw holes: 75x75mm VESA mount
- Headset audio port
|
