Basic Specification
|
Display |
TFT LCD |
21.5” (16:9 diagonal) inch configuration |
|
Number of Pixel |
1920 (H) x 1080 (V) |
|
Back-light |
LED Side-light type |
|
Media format |
Video |
MPEG-1, MPEG-2, MPEG-4, H.263, H.264, H.265, VC-1, VP9, VP8, MVC |
|
Audio |
MP2, WMA, WAV, AAC, OGG |
|
Picture |
JPG, BMP, GIF,PNG |
|
External Storage |
Micro SD card slot |
SD card (SDHC Class10 compatible) |
|
USB |
USB 2.0 Type A |
*3(2 of them shared with add-on module slot) |
|
USB 3.0 Type A |
*1 |
|
USB 3.0 Type C |
*1 |
|
Add-on Module Slot |
*3 |
|
Speaker |
3Wx2 8 Ohm |
*2 |
|
Power |
POE:
Standard : 802.3 at/af,
If matching with Zunidata specific PSE models : 48W. |
*1[Option] |
|
DC 12V/5A Adaptor |
*1 |
|
Wireless Communication |
Wi-Fi 802.11 b/g/n/ac |
*1 |
|
BT |
4.2 |
*1 |
|
Ethernet |
10/100/1000 Mbps |
*1 |
|
Audio |
Analog Interface |
Headset + microphone jack x 1 |
|
Digital Interface |
S/PDIF out x 1 |
|
Function keys |
Key button |
Vol+、Vol -、Up、Down、Exit/Enter (when in recovery mode) |
Detail Specification
Hardware
CPU
- Dual-Core Cortex-A72, up to 1.8GHz Quad Core Cortex-A53, up to 1.4 GHz
GCPU
- Mali-T860MP4 GPU, support OpenGL ES1.1/2.0/3.0/3.1/3.2, OpenCL1.2, DirectX1
System Memory
- 2GB/4GB (optional) DDR3 SDRAM
Internal Storage Memory
- 16GB/32GB (optional) eMMC
External Storage Memory
- SD Card (SDHC Class10 compatible)
LCD
- 21.5” 1920x1080 digital TFT LCD
Touch Panel Type
- 10 point capacitive multi-touch type
Amplifier, Speaker
- Speaker unit: 3W+3W 8 OHM
- Amplifier 1.25W+1.25W
- Save the set-up volume and keep the value at the time of power off and on.
Clock Battery (for RTC)
- Lithium-ion non-rechargeable coin battery
LED
- [power supply ON] , and [power supply OFF] modes are supported.
- Power supply ON: Red then turn Green after kernel boot up.
- Power supply OFF: LED light off
Wireless Communication Specification
- Wi-Fi：IEEE 802.11b/g/n/ac
- Bluetooth 4.2
Ethernet Communication Specification
- 10/100/1000 Mbps LAN RJ45 built-in
External Interface
- SD card slot
- Key button (vol+、vol-、Up、Down、Exit/Enter (when in recovery mode))
- USB Interface
USB 2.0 host type A port x3 (2 of them shared with add-on module slot)
USB 3.0 host type A port x1
USB 3.0 Type C port （USB 3.0 OTG）x 1
Add-on Module slot (USB 2.0 interface high speed 480Mbps) x 3 (option)
- Ethernet RJ45 10/100/1000 Mbps connector x 1
- RS232 x 2 (in RJ45 connector)
- Power slide switch
- DC adapter port
- VESA mount (100x100 mm)
- Headset + MIC port
- S/PDIF out |
