6.4 inch Open Frame Display Optional Touch
|
| Product Name：6.4 inch Open Frame Display Optional Touch |
 |
| Product No：162246-173 |
| Model：OF064 |
| Was Price：0Dollar/Carton Now Price：0Dollar/Carton |
| Last update：2013.06.21 |
| Manufacturer：UTG Taiwan |
| Clicks： |
|
 产品详细介绍 |
|
◆ High Contrast color TFT LCD Monitor support resolution up to SVGA.
◆ Power management system conforms to VESA DPMS andEPA Energy Star standards.
◆ Full consideration for touch screen installation and application.
◆ Universal Power adapter.
◆ Support DDC1 & DDC2B for Plug & Play compatibility
◆ Advanced OSD control for picture quality adjustment.
◆ Custom design by request. |
|
|
Specifications
|
Model Name |
UTOF640 |
| Panel Type |
PRIME VIEW 6.4-inch LCD Panel |
| Active Display Area (mm) |
129.6 (H) x 97.44 (V) |
| Pixel Pitch (mm) |
0.203 (H) x 0.203 (V) |
| Number of Pixels |
640 x 480 |
| Display color |
262,144 colors |
| Contrast Ration |
120 : 1 |
| Backlight |
2 CCFL Backlight units |
| Luminance |
300 cd/m2 |
| View Angle (CR>=10) |
-55 ~ +55 (H) ; -35 ~ +15 (V) |
| Response time (Tr+Tf) |
80 ms |
Synchronization Range
Horizontal / Vertical |
31.5 ~ 68 KHz / 56 ~ 75 Hz |
| Recommended Resolution |
640 x 480 @ 60Hz, 75Hz |
| Signal Connector |
15 pin D-Sub |
| Power Adapter |
Universal AC 100V ~ 240V, 50 ~ 60Hz input,
12V DC, 4.0A output, 48 Watt |
| Power Consumption |
15 Watt Typical ; Normal operation |
| Plug & Play |
VESA DDC 1/2B |
| Dimension (mm) |
200 x 170 x 35 |
| Option Touch |
Resistive ; Capacitive |
| Video Input |
Option |
| Media Player |
Option |
| Weight |
|
|
Download Drawing |
Specification is subject to change without notice. | | |
| |
|
|
