Model Name |
UTOF190 |
| Panel Type |
AU 19" LCD Panel ( RoHS Compliance ) |
| Active Display Area (mm) |
376.32 (H) x 301.056 (V) |
| Pixel Pitch (mm) |
0.294 (H) x 0.294 (V) |
| Number of Pixels |
1280 x 1024 |
| Display color |
16.7M colors |
| Contrast Ration |
1300 : 1 |
| Backlight |
4 CCFL Backlight units |
| Luminance |
300 cd/m2 |
| View Angle (CR>=10) |
-89 ~ +89 (H) ; -89 ~ +89 (V) |
| Response time (Tr+Tf) |
8 ms |
Synchronization Range
Horizontal / Vertical |
31.5 ~ 68 KHz / 56 ~ 75 Hz |
| Recommended Resolution |
1280 x 1024 @ 60Hz, 75Hz |
| Signal Connector |
15 pin D-Sub |
| Power Adapter |
Universal AC 100V ~ 240V, 50 ~ 60Hz input,
12V DC, 4.0A output, 48 Watt |
| Power Consumption |
30 Watt Typical ; Normal operation |
| Plug & Play |
VESA DDC 1/2B |
| Dimension (mm) |
446.6 x 33.5 x 332.4 |
| Option Touch |
Resistive ; Capacitive |
| Video Input |
Option |
| Media Player |
Option |
| Download Drawing |
|
|
Specification is subject to change without notice. |
