| System Architecture |
|
| Processer |
32bits |
| Operating Platform |
Real time OS |
| Memory Flash |
64Mb |
| Memory RAM |
32Kb |
| Power supply voltage |
DC +5V, 0.9A |
| Dimensions (WxHxL) |
182 x 131 x95mm |
| Weight |
900g |
|
|
| Output Media |
|
| Display Size |
|
| Brightness |
Brightness |
| Resolution |
128 x 64 Dots |
| Speakers |
Speaker |
| Data Ports |
|
|
LAN port 10/100 Mb |
|
RS232 |
|
Power Over Ethernet IEEE 802.3af Optional |
|
Entry/Exit Gate control function Optional (2-pin conn) |
| Network Interface |
|
|
Wired LAN Ethernet: 100MB Base-TX/10MB Base-T (802.3) standard on board |
|
Wireless LAN 802.11b/g (Optional) |
| Encryption protocols |
WEP 128 or WPA WEP 128 or WPA encryption (Optional) |
| Data Inputs |
|
| Scanner possibilities |
Scanner possibilities 1D Omni Directional Laser Scanner |
| Symbologies Supported |
Symbologies Supported Omni Directional Laser Scanner (1D) |
|
|
| Software & Applications |
|
| Application |
Easily to configure, program and maintain from a remote location. |
|
|
| Color available |
Black /Red |
|
|
| Environmental |
|
| Operating temperature |
0° ~ 40°C (32° ~ 104°F) |
| Storage temperature |
-20° ~ 60°C (-4° ~ 140°F) |
| Humidity |
20%~95% RH. (non condensing) |
