| Processor |
Marvell PXA270 CPU with 312 MHz |
| Memory |
64MB SDRAM
64MB Flash ROM + 2GB Flash Storage |
| Display and Touch Panel |
Trans-missive 2.4§ TFT 256K Color QVGA LCD with high brightness LED backlight
Resistive type touch panel |
| Audio |
Two buzzers |
| Expansion Slot |
One user accessible micro SD slot
Supports SD/SDHC memory card
Supports software image upgrade |
| I/O Connector |
Supports USB Client and power input
USB 1.1 compliant
Supports connection with USB cable, cradle, and power adaptor |
| Wireless PAN Option |
Bluetooth class II with V2.0 compliant
Range 10 m
Support WiFi coexistence |
| Wireless LAN Option |
802.11b/g Wireless LAN
Compliant with WPA and IEEE 802.11i WPA2
Cisco Compatible Extensions (CCX) Version 4 certification
Support full range of 802.1x(EAP) including EAP-TLS, EAP-FAST, LEAP, PEAP-MSCHAPv2 and PEAP-GTC
Support Static, Pre-shared and Dynamic encryption 40-bit and 128-bit keys. WEP, WPA: TKIP and WPA2:AES
Support Bluetooth coexistence |
| Battery |
Main Battery: 1100mAH, 3.7V Li-Ion smart battery pack
Extended Battery: 1830mAH, 3.7V Li-Ion smart battery pack (Optional)
One rechargeable 15mAH, 2.4V Li-MH backup battery
One battery cover sensor switch
Battery charge time:
1100mAH battery pack: 2.5 hours
1830mAH battery pack: 4.0 hours |
| Power Adapter |
100~240Vac, 50/60Hz Input
5Vdc/3Adc Wall Mount |
| Indicator |
Two-color LED charging status indicator
Red: Charging Green: Fully charged
Two-color LED scanner indicator
Red: Scanning Green: Good scan |
| Scan Engine |
Motorola SE955 1D Laser Scanner |
| Key Pad and Buttons |
23 keys numeric keypad
LED keypad backlight
Four function keys: Two direction keys; One scan key; One power button |
| Dimensions and Weight |
Dimensions: 135(L) x 50(W) x 25(H) mm
Weight: 170g including 1100mAH battery pack
190g including 2000mAH battery pack |
| Software |
WinCE 5.0 Core Version.
Backup manager, Scanner Setting utility,
User friendly SDK software development kit |
| User Environment |
Operation Temperature: -10~50℃
Storage Temperature: -25~60℃
Humidity: 95% non-condensing @ 40℃
Environmental Sealing: IP54 Standard
Free Drop: 1.2m (5ft) drop to concrete, 3 drops per 6 sides
Tumble Drop: 100 times 1.0m tumbles (200 drops)
ESD: +/-8KV Air Discharge, +/-4KV Contact Discharge |
| Regulatory Compliance |
CE, CB, FCC, NCC, SRMC, CCC, RoHS |
