| Specifications |
| Performance |
|
| Light Source |
650± 10nm VLD |
| Depth of Field |
Up to 300mm@20mil/0.5mm, PCS90% |
| Resolution |
5mil/0.127mm@PCS90% |
| Scan Rate |
50 scans per second ±5% |
| Print contrast ratio |
30% |
| Indicator |
Beep and LED (Good read Green) |
| Interface |
Keyboard wedge/RS-232/USB(HID or virtual comport) |
|
|
| Physical |
|
| Color available |
Black (Cap and Grip)/Black(Cap), Beige(Grip) |
| Dimensions (WxHxL) |
75 x 82.85 x 171.31 mm (Scanner) |
|
112.18 x 84.64 x 130.6 mm (Cradle) |
| Weight |
Scanner 225.4g, Cradle 147.4g" |
|
|
| Electronic |
|
| Input Voltage |
|
| Operating current |
Scanner 170mA, Cradle 100mA |
| Standby current |
Scanner 100mA, Cradle 55mA |
|
|
| Wireless Characteristics |
|
| Wireless Standard |
Bluetooth V2.1 Standard, support both SPP and HID profiles |
| Battery type |
Li-ion 3.7V ,2600 mAh |
| Charge Time |
Approx. 5 hours |
| Scans per charge |
50,000 times in continuous read |
| Radio Transmission Range |
Class 1 up to 100m / 328.08 ft. line of open sight |
|
|
| Environmental |
|
| Ambient light |
Up to 5,000 Lux |
| Operating temperature |
0°C to 50°C(32°F to 122 °F) |
| Storage temperature |
-20°C to 70°C(-4°F to 158 °F) |
| Drop resistance |
47.24 inches(120cm) |
| IP Sealing |
IP42 |
|
|
| Symbologies |
Automatically discriminates major standard 1D bar codes, include GS1 databar - Omnidirectional, Expanded and Limited codes. |
